Corrugated Steel Liner Tanks
Built tough in ZINCALUME® steel or in the full range of COLORBOND® colours.
Corrugated Steel Liner Tanks
Available from 26,000 litres up to 2.3 million litres.
Corrugated Steel Liner Tanks
Suitable for fire, potable water and agriculture applications.
Rhino Corrugated Liner Range
Our range of Rhino corrugated commercial tanks are built tough in ZINCALUME® steel or in the full range of COLORBOND® colours.
Tanks range from 26,000 litres up to 2.3 million litres. A variety of different tank liner materials are available to suit.
We have a network of specially trained tank installers around Australia. Our installers focus on quality and excellent service to ensure the project is supplied and installed to the customer’s specific requirements.
All commercial tanks are transported to site in flat pack form and then assembled on site. This gives us the ability to install tanks on sites with reduced accessibility. Larger tanks may be assembled with the use of cranes and elevated work platforms.
Suitable Applications
-
Fire Fighting
-
Potable Water
-
Agriculture and Horticulture
-
Stormwater Retention
-
Irrigation
-
Dust Suppression
-
Treated Water
-
Process Water
PRoduct information
Our range of Rhino corrugated commercial tanks are built tough in ZINCALUME® steel or in the full range of COLORBOND® colours. Tanks range from 26,000 litres up to 2.3 million litres. A variety of different tank liner materials are available to suit the stored
| Tank | Tank Diameter | 2.2m High | 2.9m High | 3.6m High | 4.3m High | 5m High |
|---|---|---|---|---|---|---|
| RCT-25 | 3.884m | 26,062 | 34,355 | 42,631 | 50,947 | 59,240 |
| RCT-40 | 4.855m | 40,723 | 53,680 | 66,639 | 79,637 | 92,601 |
| RCT-60 | 5.826m | 58,640 | 77,299 | 95,920 | 114,615 | 133,291 |
| RCT-80 | 6.797m | 79,816 | 105,212 | 130,597 | 156,004 | 181,400 |
| RCT-100 | 7.768m | 104,250 | 137,420 | 170,525 | 203,761 | 236,931 |
| RCT-130 | 8.739m | 131,941 | 173,922 | 215,871 | 257,884 | 299,866 |
| RCT-160 | 9.710m | 162,890 | 214,719 | 266,466 | 318,376 | 370,205 |
| RCT-200 | 10.681m | 197,097 | 259,810 | 322,461 | 385,235 | 447,948 |
| RCT-230 | 11.652m | 234,562 | 309,195 | 383,683 | 458,461 | 533,095 |
| RCT-275 | 12.623m | 275,284 | 362,875 | 450,366 | 538,055 | 625,646 |
| RCT-320 | 13.594m | 319,264 | 420,849 | 522,433 | 624,017 | 725,601 |
| RCT-360 | 14.565m | 366,503 | 483,117 | 599,587 | 716,346 | 832,960 |
| RCT-420 | 15.536m | 416,998 | 549,680 | 682,361 | 815,042 | 947,724 |
| RCT-470 | 16.507m | 470,752 | 620,537 | 770,124 | 920,106 | 1,069,891 |
| RCT-530 | 17.479m | 527,764 | 695,688 | 863,613 | 1,031,538 | 1,199,463 |
| RCT-590 | 18.450m | 588,033 | 775,134 | 962,236 | 1,149,337 | 1,336,438 |
| RCT-650 | 19.421m | 651,560 | 858,875 | 1,066,189 | 1,273,504 | 1,480,818 |
| RCT-720 | 20.392m | 718,345 | 946,909 | 1,175,473 | 1,404,038 | 1,632,602 |
| RCT-790 | 21.363m | 788,388 | 1,039,238 | 1,290,089 | 1,540,939 | 1,791,790 |
| RCT-860 | 22.334m | 861,688 | 1,135,862 | 1,410,035 | 1,684,209 | 1,958,382 |
| RCT-940 | 23.305m | 938,246 | 1,236,779 | 1,535,321 | 1,833,845 | 2,132,378 |
| RCT-1010 | 24.276m | 1,018,063 | 1,341,992 | 1,665,920 | 1,989,849 | 2,313,778 |
